12 inch Wifi NVR Kits
Feature: Black
1: 4ch wifi lcd nvr kits
2: Plastic
3: 960P wifi NVR KIT
5: WINBO
Details

960P Full HD Wireless IR IP CCTV Camera LCD 4CH 12 Inch NVR Security System DIY Kit





Product Details


Features


HD video output


Automatic connection with IP, save installation cost

Plug and play, P2P service


Mobile viewing, iphone&android app


Free DDNS :www.e-seenet.com,no need DDNS setting

Specifications

Operating SystemEmbedded Linux OS
Screen Build in 12 inch HD LCD Screen (resolution:1280*1024)
Network Video4CH
Network video input broadbank 20Mbps
AUdio Bitrate64Kbps
HDMI input1ch,resolution:1024x768,1366x768,
1440x900,1920x1080p
VGA output1ch,resolution:1024x768,1366x768,
1440x900,1920x1080p
Video Resolution960P
synch-playback4CH
Video/Capture modeMaual,Time,Motion,Alarm
Playback modeReal time,Routine,Event
BackupUSB backup
Alarm Input 4ch/8CH (optional)
Alarm Output 1ch (optional)
Type1*SATA interface
Max Capacity4 TB at most for each
Network Interface1 adaptable RJ45 10M/100M, 1 WIFI interface
USB Interface2 USB 2.0
ProtocolUPnP (play&plug)/SMTP (email survice)/PPPoE (dial-up)
DHCP (Automatically obtain an IP address), etc…
Power SupplyDC12V3A
Power Consumption (W) ≤5W(Without HDD)
Operate Temperature (°C)-10℃~+55℃
Working Humidity (%) RH10%~90%
Size257mm(W)×210mm(V)×45mm(H)
Weight(excluding HDD)≤1Kg
Sensor1/4" Progressive Scan Sensor
Signal SystemPAL/NTSC
Resolution960P
Minimum illuminationColor: 0.1 Lux; B/W: 0.01 Lux
Shutter1/25s to 1/25,000s
Lens3.6mm
OSDDate Time & Title
White BalanceAuto
Day&NightAuto / Color / BW
3D-DNRAuto
Mirror/FlipOn / Off
Frame SpecificationThree Streaming at the Same Time:
H.264 128x720@30fps or below
H.264 640x480@30fps or below
S/N> 39.1 Db
InterfaceRJ45 / WIFI 802.11b/g/n
Anti-thunder LevelStandard IEC61000-4-5
Working Temperature-20℃ to +60℃ / 20% to 90% RH
Power InputDC12V-1A
Power consumption≤6W
Size205(L)×70(W)×55 (H)mm
Weight500g
Level of ProtectionIP66
